Description
Meiyuan T-F3003WL Self Wound Aluminum Foil Tape is a 30u nominal dead soft aluminum foil with silicone release coating on its back and water based acrylic adhesive on close side.
Features
¨ Without Liner, Easy Application ¨ Good Moisture
¨ Outstanding Temperature & Aging Resistance
Applications
Commercial grade 30u foil tape without liner. Good for sealing joints / seams against moisture and vapor on foil jacketing insulation. Suitable for many other sealing, holding, splicing or masking applications requiring the protection offered by a foil backing
Technical Data Sheet
Property | Unit | Value | Test Method |
Backing Thickness | Micron | 30 | PSTC-33 / ASTM D3652 |
Peel Adhesion | N/25mm | 15 | PSTC-1 / ASTM D3330 |
Tack Rolling Ball | cm | 5 | PSTC-6 / ASTM D3121 |
Tensile Strength | N/25mm | 37.5 | PSTC-31 / ASTM D3759 |
Elongation | % | 3.0 | PSTC-31 / ASTM D3759 |
Service Temperature | °C | -30 ~ +60 | ---------- |
Applying Temperature | °C | +10 ~ +40 | ---------- |
Cut Roll:
48mm, 50mm (2"), 60mm, 63mm (2.5"), 72mm, 75mm (3"), 96mm, 100mm (4").
