Self-adhesive Aluminum Foil Glass Fiber Tape Roll

The product is made of glass fiber cloth and aluminum foil , and is coated with high - grade pressure - sensitive adhesive on the glass fiber cloth layer , and then is separated by anti - sticking paper .

Specification:

Cut Roll:  48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4")

Log Roll: 1200mm x 45 / 50m

Jumbo Roll: 1200mm x 500m / 750m

Aluminum foil thickness: 18 microns to 80 microns

Width: 50mm - 1200mm , length is cut and customized according to customer ' s requirements . The thickness of glass fiber cloth and aluminum foil can be customized according to your needs. Welcome to your inquiry !

 TYPE & SIZE

APPLICATION:

Vehicle , vessel , airplane , carriage , fuselage , cabin , etc. and the heat insulation and sound insulation decoration of large - sized high - grade buildings . It has the characteristics of no toxicity , no smell , flame retardant , heat insulation , sound insulation , convenient use , etc.

For the metal material , the joint sticking of the aluminum foil composite material , the sealing at the puncture point of the thermal insulation nail and the repair of the broken part are the necessary materials for the production of the refrigerator and the ice bin , and also the primary raw material of the heat insulation refrigeration equipment and the heating pipeline .

Used for various electronic products such as various transformers , mobile phones , computers , PDAs , PDPs , LCD displays , notebook computers , copying machines and the like , has the advantages of anti - electronic interference , separation of electromagnetic waves , use of pure aluminum foil as a base material , uniform coating of special adhesive with high difficulty performance , and no release paper . The peeling strength is high , the initial viscosity is good , the cohesion is excellent , flame resistance , weather resistance and high low temperature performance are good .

The product is widely used in the fields of refrigerator, air conditioning , automobile , petrochemical , bridge , hotel , electronics , etc. Aluminum foil can not only be compounded with glass fiber cloth of different specifications, but also can be compounded with Kevara , carbon fiber cloth , flame - retardant cotton cloth , aluminum silicate ceramic cloth , silica gel cloth , pearl cotton , non - woven fabric and the like , and is a good heat - insulating and insulating material . The product is mainly applied to pipeline protection, automobile , building, etc .

ATTENTION:

1. The data above are typical values only, and should not be used for specifications purpose.

2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Cut Roll: ±0.3m, Jumbo Roll ±0.5%.

STORAGE:

12 months when stored at 21°C (70°F) / 50% relative humidity out of direct sunlight.

SURFACE PREPARATION:

It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied must be clean, dry, free of grease, oil or other contaminants.

HOW TO USE:

It is essential that the user evaluate the BondTape product to determine whether it is fit for a particular purpose and user’s method of application. Good results will be obtained when applied to a clean, dry surface with a suitable pressure on BondTape products between +10 ~ +40°C (+50 ~ +105 °F).
